Przemyslaw Musialski
Reduced-Order Shape Optimization Using Offset Surfaces, 24. June 2015, Institute of Science and Technology (IST), Austria

Information

  • Publication Type: Invited Talk
  • Workgroup(s)/Project(s):
  • Date: 2015
  • Event: SIGGRAPH Nano @ Institute of Science and Technology (IST), Austria
  • Location: Institute of Science and Technology (IST), Austria
  • Conference date: 24. June 2015
  • Keywords: geometry processing, digital fabrication, shape optimization

Abstract

Given the 2-manifold surface of a 3d object, we propose a novel method for the computation of an offset surface with varying thickness such that the solid volume between the surface and its offset satisfies a set of prescribed constraints and at the same time minimizes a given objective functional. Since the constraints as well as the objective functional can easily be adjusted to specific application requirements, our method provides a flexible and powerful tool for shape optimization. We use manifold harmonics to derive a reduced-order formulation of the optimization problem, which guarantees a smooth offset surface and speeds up the computation independently from the input mesh resolution without affecting the quality of the result. The constrained optimization problem can be solved in a numerically robust manner with commodity solvers. Furthermore, the method allows simultaneously optimizing an inner and an outer offset in order to increase the degrees of freedom. We demonstrate our method in a number of examples where we control the physical mass properties of rigid objects for the purpose of 3d printing.

Link: https://ist.ac.at/events/symposia-conferences/2015/siggraph-nano-ist-austria/date/433/

Additional Files and Images

Additional images and videos

thumbnail: thumbnail thumbnail: thumbnail

Additional files

slides: slides slides: slides

Weblinks

No further information available.

BibTeX

@talk{musialski-2015-ista,
  title =      "Reduced-Order Shape Optimization Using Offset Surfaces",
  author =     "Przemyslaw Musialski",
  year =       "2015",
  abstract =   "Given the 2-manifold surface of a 3d object, we propose a
               novel method for the computation of an offset surface with
               varying thickness such that the solid volume between the
               surface and its offset satisfies a set of prescribed
               constraints and at the same time minimizes a given objective
               functional. Since the constraints as well as the objective
               functional can easily be adjusted to specific application
               requirements, our method provides a flexible and powerful
               tool for shape optimization. We use manifold harmonics to
               derive a reduced-order formulation of the optimization
               problem, which guarantees a smooth offset surface and speeds
               up the computation independently from the input mesh
               resolution without affecting the quality of the result. The
               constrained optimization problem can be solved in a
               numerically robust manner with commodity solvers.
               Furthermore, the method allows simultaneously optimizing an
               inner and an outer offset in order to increase the degrees
               of freedom. We demonstrate our method in a number of
               examples where we control the physical mass properties of
               rigid objects for the purpose of 3d printing.    Link:
               https://ist.ac.at/events/symposia-conferences/2015/siggraph-nano-ist-austria/date/433/",
  event =      "SIGGRAPH Nano @ Institute of Science and Technology (IST),
               Austria",
  location =   "Institute of Science and Technology (IST), Austria",
  keywords =   "geometry processing, digital fabrication, shape optimization",
  URL =        "https://www.cg.tuwien.ac.at/research/publications/2015/musialski-2015-ista/",
}
